Description
 |
Imported THK high accuracy mute track |  |
High quality DC servo motor with good stability and long service life |
 |
Standard equipped with intelligent infrared heating and air drying system |  |
It can print whole roll with 3.2m width material, especially suitable for the production of high-precision inkjet cloth. Two rolls 1.27m width material can be printed at the same time (air-expansion shaft feeding & collecting system can be choose for the special textile material) |
 |
Automatic moisturizing,
cleaning module ensures the, cleaning and working stability |
 |
Print heads collision avoidance system can effectively prevent the head from crashing during printing |
Additional Information
| Model | E3204 | E3202 | |||
| Head Model | EPSON I3200-A1 | EPSON I3200-E1 | |||
| Ink Model | CMYK | ||||
| Wide Application | Indoor and outdoor PP and photo paper, car sticker, water – based backlit film, eco-solvent lamp, canvas, non-wovenCloth, digital printing materials, etc. | ||||
| Print width | 3.2M | ||||
| Medium | Width | 3.2M | |||
| Thickness | 1MM | ||||
| Weight | 80KGS | ||||
| Ink cartridge | Type | Solvent/water-based/Sublimation | |||
| Volume | 220cc 2ndcartridge +3.0L Big volume ink-bottle with float | ||||
| Color | Four Color | ||||
| Printing resolution | EPSON I3200-A1（Maximum 1440dpi） | EPSON F1440-A1（Maximum 2400dpi） | |||
| Head qty | 2PCS | 4PCS | 2PCS | 4PCS | |
| Printing speed | 3pass:60m2/h4pass:42m2/h
6pass:30m2/h |
3pass:120m2/h
4pass:84m2/h 6pass:60m2/h |
4pass:44m2/h
6pass:32m2/h 8pass:22m2/h |
4pass:88m2/h
6pass:64m2/h 8pass:44m2/h |
|
| Size | 4574MM*968MM*1489MM | ||||
| Net Weight | 880KGS | ||||
| Wooden box package | 4800MM*1070MM*1680MM | ||||
| Gross Weigh | 980KGS | ||||
| Interface | USB2.0 | ||||
| Heating system | Integrated heater, infrared dryer and fan system | ||||
| Power | AC220V,50/60HZ | ||||
